Description

55 TONS IN ANY 12`
(4) I-BEAM, CAMBERED, T-1 STEEL
8`-6
26`
22/6 LOADED (ADJUSTABLE)
ON 20 CENTERS
STEEL WITH TRACTION BARS
FOR A 3+1 (14`-1 SPREAD)
OUTSIDE OF OUTER BEAMS ONLY
LAST 3 CROSSMEMBERS OF DECK
FROM TRACTOR WETLINE
NON-GROUND ENGAGING REMOVABLE-HI LIFT
HYDRAULIC
PIN & STIRRUP TYPE W/ VERTICAL AIR LOCK PIN
108 & 84
48-50-52-54-56 LOADED (ADJUSTABLE)
OVER GOOSENECK AREA
AT REAR OF GOOSENECK
AT REAR OF GOOSENECK
16.5 X 7 W/ AUTO SLACKS & OUTBOARD DRUMS
NONE (TRAILER GVWR EXCEEDS 120,000#)
ON ONE AXLE
(3) 25,000# 3/4 WALL W/ 23,000# BRAKES AND LIMIT CHAINS
(12) 275/70R22.5 (H)
STEEL DISC, 10-HOLE, HUB PILOTED, 8.25 X 22.5
AIR RIDE W/ 55 AXLE SPACING
W/ CHART
AIR LIFT 3RD AXLE ONLY
+3/-3 HEIGHT CONTROL, AUTO/MANUAL WITH WHITTLE ARM
AT REAR OF TRAILER
L.E.D. RUBBER SEALED SYSTEM
IN 3RD TAIL LIGHT POSITION W/ SWITCH
W/ RECHARGEABLE FEATURE
(18) TOTAL, 6-PER SIDE, BENT STYLE, 1-EACH SIDE FRONT OF DECK FLAT STYLE ON 45 DEGREE ANGLE, 1-EACH BOLSTER END FLAT STYLE
12 SWING/REMOVABLE WITH DOUBLE HOOK-ON FRONT. FULL LENGTH OF DECK
1-1/2 APITONG (FULL WIDTH)
GLOSS BLACK (2-PART URETHANE) STEEL PARTS TO MATCH PAINT COLOR
OPEN BOTTOM W/EXTRA LOW 1ST CROSSMEMBER (NO COVER PLATE)
ON FRONT & REAR SLOPES
ON BOLSTERS
1-PAIR FRONT CORNER OF DECK, 1-PAIR ENDS OF LIGHT PANEL
FOR FUTURE FLIP/REMOVABLE AXLE
